Clamping heads use a flexible segmented clamping element to support workpieces over a broader contact area than a rigid jaw contact. TOP-TOOL lists through-hole, blind-hole and related clamping head workholding options for internal and external clamping RFQ review.
How to Select Clamping Head Systems
Confirm workpiece bore or outside diameter, through-hole or blind-hole condition, contact length, material, machining allowance, clamping direction and machine or fixture interface.
Typical Applications
- Internal bore clamping
- Sleeve and tube machining
- Flexible contact support for round parts
- Blind-hole workpiece holding
- RFQ-based workholding projects where contact area must be reviewed
Representative Products
- SB170 | Through-Hole Segmented Clamping Bushing
- SB270 | Segmented Clamping Bushing for Blind Holes
- 7 | Blind-Hole Expanding Mandrel
- JAB-SK65 | JAB-SK High-Speed Pneumatic Clamping Head Chuck
- 100 mm | Vertical Fixed Hydraulic Clamping Head Chuck
- 160 mm | Clamping Head
- KB170 | Through-Hole Expanding Mandrel
- 160 mm | Through-Hole Clamping Head Chuck
Related TOP-TOOL Pages
- Expanding Mandrels
- Collet Chucks
- Diaphragm Chucks
- Hydraulic Chucks
- Machine Tool Accessories
- Request a Quote
Clamping Head Systems FAQ
What are Clamping Head Systems used for?
Clamping Head Systems are used for machine tool workholding, setup or accessory matching where the machine, interface and workpiece requirements must be checked before selection.
What information is needed for a quote?
Send the machine model, interface or mounting details, workpiece drawing or size, required model or range, quantity and application notes.
How do I choose between types or models?
Compare the machine interface, workpiece size, clamping or holding method, required clearance and model-level specifications. If the fit is uncertain, request RFQ review before ordering.
Is this category handled by RFQ or online purchase?
This category is normally handled as RFQ because final suitability depends on the actual machine, interface, workpiece and application details.
What related products should I compare?
Compare the related TOP-TOOL pages listed on this collection page, especially neighboring workholding or machine tool accessory categories that share machine-interface or setup requirements.
Are listed specifications final compatibility guarantees?
No. Listed data is for model identification and quotation review. Final suitability should be confirmed against the actual machine, workpiece, setup and operating conditions.
Request a Quote with your machine, workpiece, product model or application details.
